Description
LED indication: Star relay ON, Delta relay ON
Accuracy setting: ?5% of F.S.
Repeat: ? 0.5% or 50msec (F.S.= Full scale)
Relay contact: 2C/O (SPDT
Contact rating: 5A @250V AC or 24V DC Resistive
Modes: On delay/Interval
Time ranges: 0-3 sec/min, 0-10 sec/min,0-30 sec/min, 0-60 sec/min
Resolution: 0.3 sec
Reset: ON power interruption,Reset time <100 msec Supply voltage: 20 to 240V AC (50/60 Hz),18 to 240V DC Power consumption: 2VA max Temperature: Operating: 00 to 50 ?C (32 to 122 ?F)Storage: -20 to 75 ?C (-4 to 167 ?F) Humidity (Non-condensing): 95% RH Mounting: DIN rail Weight: 129 gm
