Description
LED indication: Star relay ON, Delta relay ON
Accuracy: ?5% of F.S.
Repeat: ? 0.5% or 50msec (F.S.= Full scale)
Relay contact: 1C/O SPDT
Contact rating: 5A @250V AC or 24V DC Resistive
Modes: ON delay/Interval
Time ranges: 0-3 sec/min, 0-10 sec/min,0-30 sec/min, 0-60 sec/min
Resolution: 0.3 sec
Reset: ON power interruption,Reset time <100 msec Supply voltage: 230V AC & 24V AC/DC (50/60 Hz)- 15% to 10% tolerance Power consumption: 6VA max Temperature: Operating: 00 to 50 ?C (32 to 122 ?F)Storage: -20 to 75 ?C (-4 to 167 ?F) Humidity (Non-condensing): 95% RH Mounting: DIN rail Weight: 84gm
