Description
LED INDICATION: STAR RELAY ON DELTA RELAY ON
ACCURACY: SELTING:?5% OF F.S,REPEAT:?0.5% OR 50M SEC(F.S=FULL SCALE)
RELAY CONTACT: 1C/O Relay each for star & delta
Contact rating: 5A @250V AC/24V DC, Resistive
ModeS: Star-delta
Time ranges: Runup time range: 30/60 sec,Change over: 50/100msec(User selectable via DIP switches)
Reset: ON power interruption,Reset time <100 msec Supply voltage: 230V AC (50/60 Hz)-15% to 10% tolerance Power consumption: 10VA max Temperature: Operating : 00 to 50 ?C (32 to 122 ?F)Storage : -20 to 75 ?C (-4 to 167 ?F) Humidity (non - condensing): Upto 95% RH Mounting: DIN rail Weight: 115 gm
