Description
LED indication: Star relay ON, Delta relay ON
Accuracy setting: ?5% of F.S.
Repeat: ?0.5% or 50 msec (F.S. = Full scale)
Relay contact: 2C/O SPDT
Contact rating: 5A @250V AC or 24V DC resistive
Modes: ON delay/Interval
Time ranges: 0-1 sec/min/hr, 0-3 sec/min/hr, 0-10 sec/min / hr, 0-30 sec/min/hr
Resolution: 0.1sec
Reset: ON power interruption,Reset time <100 msec Supply voltage: 20 to 240V AC (50/60Hz), 18 to 240V DC Power consumption: 2VA max Temperature: Operating: 00 to 50 ?C (32 to 122 ?F)Storage: -20 to 75 ?C (-4 to 167 ?F) Humidity (non - condensing): 95% RH Mounting: DIN rail Weight: 115 gm
