Description
Condition: ?R? LED
Nominal condition: ON
Fault condition: OFF
Accuracy: ?3% of F.S. (F.S.= Full scale)
Reset: Auto reset on removal of fault condition
Relay contact: 1C/O (SPDT)
Relay rating: NO/5A, NC/3A @250V AC
Operating voltage: 154 to 500V AC (L-L)
Nominal frequency: 50/60 Hz (?10%)
Phase failure trip,Phase failure trip,Phase asymmetry,Hysteresis,Trip accuracy,Response time,Power on delay,: <154V AC (L-L),Yes,30V fixed,6V,?10V,250m sec max 250m sec max Temperature: Operating: 00 to 50 ?C (32 to 122 ?F)Storage: -20 to 75 ?C (-4 to 167 ?F) Humidity (Non-condensing): Upto 95% RH For PCB: 2 For product: 3 Degree of protection devices: IP20 Mounting: DIN rail Weight: 62 gm (0.163 lbs) Supply voltage: 154 to 500V AC
